Voopoo Drag 5 Starter Kit Review
The Voopoo DRAG 5 Starter Kit pairs a 5W to 177W box mod, powered by two 18650 batteries, with the 5.5ml UFORCE-X Tank for PnP X coils. It has Smart, RBA, ECO and temperature control modes, a 0.96-inch screen and a three-way lock slider. See more from Voopoo or compare other box mod kits.
DRAG 5 Highlights
Dual 18650, 177W
The Voopoo DRAG 5 runs on two 18650 batteries, which you buy separately, from 5W to 177W.
Lock Slider
A slider on the side locks the adjustment buttons, locks everything or turns the mod off.
Four Modes
Smart sets the power for your coil, RBA gives you the full range, and there are ECO and temperature control.
UFORCE-X Tank
The 5.5ml tank fills from a sliding top and takes every PnP X coil.
DRAG 5 Specs
Mod
- Batteries: two 18650s, not included
- Output: 5–177W
- Modes: Smart, RBA, ECO, temperature control
- TC wire: Ni, Ti, SS316, SS430
- Chip: GENE TT 2.0
- Controls: fire button, two adjustment buttons, lock slider
- Screen: 0.96-inch TFT
- Charging: USB-C, rated 5V/3A
- Size: 89.3 × 55.09 × 27.4mm
- Weight: 156.58g, without batteries or tank
- Body: zinc alloy and leather
Tank
- Tank: UFORCE-X Tank, 5.5ml
- Fill: sliding top fill
- Airflow: adjustable dual top slots
- Drip tip: 810
- Coils: PnP X, 0.15–1.0Ω
Colors
- Options: Black, Gradient Blue, Gradient Brown, Green, Sakura Pink, Silver, Sunset Orange
DRAG 5 PnP X Coils and Wattage
The DRAG 5 kit’s tank takes every PnP X coil. Voopoo rates them like this:
| Coil | Voopoo rating |
|---|---|
| PnP X 0.15Ω | DTL, 60–80W |
| PnP X 0.2Ω | DTL, 40–60W |
| PnP X 0.3Ω | DTL and RDL, 32–40W |
| PnP X 0.45Ω | RDL, 25–32W |
| PnP X 0.6Ω | MTL and RDL, 18–23W |
| PnP X 0.8Ω | MTL, 12–16W |
| PnP X 1.0Ω | MTL, 10–13W |
The 0.15Ω and 0.3Ω come in the box. We sell PnP X coils in all seven resistances. Our coil compatibility guide shows how each coil draws and which kits it fits.
Batteries
Use a matched pair of high-drain 18650s from a known brand, and charge, use and replace them together. Don’t charge batteries overnight, and carry spares in a case. The FDA has more battery safety tips.
How to Set Up the DRAG 5
- Add batteries: open the battery door and fit two charged 18650s, matching the markings.
- Fit a coil: push a PnP X coil into the tank’s base until it sits flush.
- Fill and wait: slide the top open, fill the tank and give the coil 5 minutes to soak.
- Set the power: use Smart mode, or start at the low end of your coil’s range in RBA mode.
- Lock it: move the slider to lock the buttons before it goes in a pocket.
What Hands-On Reviews Say About the DRAG 5
Hands-on reviews found the DRAG 5 solid and well made, with a clear screen that’s easy to read. One got about a day of heavy vaping at 38W from a pair of 2800mAh 18650s, and a few hours near 100W. Another called the lock slider a great feature for pocket carry.
Reviews split on the coils in the box. One preferred the 0.15Ω at about 70W. The other preferred the 0.3Ω at 35–40W for a restricted DTL draw. One review found the kit gets hot at high power, and overfilling the tank can leak from the airflow. It’s big, not discreet.
Who the DRAG 5 Is For
The Voopoo DRAG 5 suits vapers who want a dual 18650 box mod kit with swappable batteries and the full PnP X coil range. For a built-in battery and up to 220W, see the DRAG 6. For a smaller pod mod on the same coils, see the DRAG S3.
Good to know: Charging over USB-C is slow, so an external charger is quicker. The ECO mode and battery tester add little.
What’s in the DRAG 5 Box
- Voopoo DRAG 5 mod
- UFORCE-X Tank, 5.5ml
- Spare 5.5ml glass
- PnP X 0.15Ω and 0.3Ω coils
- Silicone rubber pack
- USB-C cable
- User manual
Batteries are not included.
